P L A N N I N G A N D D E S I G N G U I D E

V I K I N G R A N G E . C O M

1 - 8 8 8 - V I K I N G 1

R E L E A S E D 8 / 6 / 0 8

© 2 0 0 8 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E

All models include

Exclusive VSH™ (Vari-Simmer to High)

Patented Sealed Burner System

o Exclusive – most powerful sealed

burners in the industry

o Four 15,000 BTU burners

Exclusive VariSimmer™ setting for all

burners

Exclusive all burners equipped with

SureSpark™ Ignition System for
consistent and reliable ignition every
time

Exclusive one piece tooled and

porcelainized cooking surface for easy
clean up

Exclusive – largest self-clean oven

cavity in the industry
o Overall capacity—4.7 cu. ft.

(25-5/16”W. x 16-1⁄2”H. x
19-1/2”D.)

o AHAM Standard oven capacity—

4.1 cu. ft. (25-5/16”W. x 16-1⁄2”H.
x 16-13/16”D.)

Exclusive patent-pending Vari-Speed

Dual Flow™ convection system has
the largest convection fan in the
industry; the 8 1/2" fan works bi-
directionally for maximum airflow and
excellent cooking results

• Concealed 10-pass dual bake

element provides precise
temperature control

• Extra large Gourmet Glo™ glass

enclosed infrared broiler provides
superior broiling performance

• Rapid Ready™ Preheat provides one

of the fastest preheat times – so your
oven is ready to begin cooking when
you are

• Oven has six porcelain coated rack

supports and comes standard with
one TruGlide™ full extension oven
rack and two standard oven racks

• Three strategically located oven lights

provide maximum visibility

• Heavy-duty broiler pan and tray with

rack provide more roasting and
broiling options

• High performance cooking modes

include Bake, Convection Bake,
TruConvec™ convection cooking,
Convection Roast, Hi, Medium, and
Low Broil, and Convection Broil

• Concealed 10-pass dual bake element

makes for easy clean up of the oven
cavity

VDSC530-4B

30”W. Four-Burner Range

o Has black porcelain grates, black

porcelain burner caps, black
porcelain grate supports/burner
bowls, and black knobs/switches.

• White (WH)

o Finish designates door front, lower

front panel, side panels, porcelain
grate supports/burner bowls,
porcelain center worktop, and
knobs/switches.

o Has black porcelain grates and black

porcelain burner caps.

FINISH DETAILS FOR ALL MODELS

• Stainless Steel (SS), Black (BK), White

(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
o Finish designates door front, lower

front panel, and side panels.

Standard Features & Accessories

Model Options

COOKING

Professional Custom Series Freestanding Dual Fuel

Self-Clean 30”W. Sealed Burner Range

*Shown throughout with 8”H. backguard. See Installation Notes & Accessories for details.

ORDERING INSTRUCTIONS

First specify model number, and then color code (VDSC530-4BSS). If ordering optional brass trim, specify code at end (VDSC530-4BSSBR).
If ordering optional LP conversion, specify code at end (VDSC530-4BSSBRLP).

• All finishes have stainless steel

handle/chrome-plated brackets and
stainless steel drip tray pull, control
panel, and landing ledge.

• Brass Trim Option (BR)—nameplate,

window trim, handle, drip tray pull,
knob bezels, thermal-convection switch
bezel, and grate support side trim.
Brass components have a durable
protective coating for maintenance-
free normal use.
