User's Manual - 81
Recording name: Enter a descriptive name for the recording setting�
Enable this recording: Select this option to enable video recording�
Priority: Select the relative importance of this recording setting (High, Normal, and Low)�
Source: Select the recording source (stream 1 or stream 2)�
Recording Schedule: Specify the recording duration�
■ Select the days on weekly basis.
■ Select the time for recording in 24-hr time format.
Destination: Select a network storage you’ve setup for the recorded video files.
Capacity: You can choose either the entire free space or limit recording size� The limit recording size
must larger than the reserved amount for cyclic recording�
File name prefix: Enter the text that will be put in front of the file name.
Enable cyclic recording: If you check this item, when the maximum capacity is reached, the oldest file
will be overwritten by the latest one� The reserved amount is reserverd for cyclic recording to prevent
malfunction� This value must larger than 15 MBytes�
If you want to enable recording notification, please click Application to set up� Please refer to Trigger >
Recording notify on page 68 for detailed information�
When completed, select Enable this recording� Click Save to take effect and then click Close to quit
this page. The system begins recording and send recorded files to the Network Storage.
The new recording name will appear in the recording drop-down list on the recording page as below�
To remove a recording setting from the list, select a recording name from the drop-down list and then
click Delete�
■ Click Video : Open the Recording Settings page to modify�
■ Click ON : The Status will become OFF and stop recording�
■ Click NAS : Open the recorded file list as below. For more information about folder naming rule, please
refer to page 77 for details�
20081120
20081121
20081122
