background image

P L A N N I N G A N D D E S I G N G U I D E

V I K I N G R A N G E . C O M

1 - 8 8 8 - V I K I N G 1

R E V I S E D 5 / 2 / 1 1

© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

VENTILATION

Built-In 10”H. Wall Hood w/Ventilator/

12”H. Chimney Wall Hood w/Ventilator

Duct Cover Extension

• For DCH hoods
• 16”W. x 12”D. x 28 – 40”H.
• Extends height of hood by up to 12” (for 10’ ceilings)
• Replaces adjustable duct cover supplied standard with hood
• Specify finish code following accessory model number (for example, DCCE1610-SS)
• Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),

Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).

Backsplashes

• Stainless Steel (SS)
• 30”H.
• For both VWH & DCH hoods
• Backsplashes protect the wall space below hood
• Create a continuous finish between cooking surface and hood
• Low maintenance, easy to clean
• Hemmed edges with screw holes
• Kit includes backsplash and fastening screws

Warming Shelf Panels

• Stainless Steel (SS)
• 12”D. X 12”H.
• For both VWH & DCH hoods
• Shelf panels hold cookware and condiments
• Kit includes shelf (or shelves) and fastening screws
• Fold up/down, heavy-duty warming shelves (non-removable), factory installed on stainless steel backsplash
• 5-7/8”W. X 10-1/8”D.

Compliance Information

WARRANTY SUMMARY*

• Three-year full warranty—complete product (Professional and Designer)
• Five-year limited warranty—all ventilator motors (Professional and Designer)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items (Professional and Designer)

* For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

Installation Notes & Accessories

Model

Description

Approx. ship wt. lbs. (kg)

DCCE1610

Designer duct cover extension

7 (15.4)

Model

Description

Approx. ship wt. lbs. (kg)

BKS24

24”W. backsplash

5 (2.3)

BKS30

30”W. backsplash

7 (3.2)

BKS36

36”W. backsplash

9 (4.1)

Model

Description

Approx. ship wt. lbs. (kg)

WGP24

24”W. warming shelf panel (one shelf)

6 (2.7)

WGP30

30”W. warming shelf panel (one shelf)

9 (4.1)

WGP36

36”W. warming shelf panel (two shelves)

12 (5.4)
