P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
Recirculating Hood Conversion Kits
• Stainless Steel (SS)
• Eliminates ducting
• Kit includes
o Two charcoal filters
o Installation hardware
o Top vent/grille
• Professional—4”H. x 12”D.
• Designer—2”H. x 12”D.
Charcoal Filters
• For use with VRK & DRK conversion kits
• Recommended replacement every 6 – 12 months
Duct Covers
• Specify finish code following accessory model number (for example, DCW24-SS)
o Professional models
• For VWH hoods
• 12”D.
• Extends height of hood by 12”—conceals duct
• Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).
o Designer models
• For DCH hoods
• For 8’ – 9’ ceilings
• Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).
• Not needed if using a DCCE1610
✪ Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
VRK24 Professional 24”W. conversion kit 10 (4.5)
VRK30 Professional 30”W. conversion kit 13 (5.9)
VRK36 Professional 36”W. conversion kit 16 (7.3)
DRK30 Designer 30”W. conversion kit 15.4 (7)
DRK36 Designer 36”W. conversion kit 15.4 (7)
Model Description Approx. ship wt. lbs. (kg)
CFV11 Professional hood filter for 24”W. 1 (0.5)
CFV13 Professional hood filter for 30”W. & 36”W. 2 (0.9)
CF-D12 Designer hood filter for 30”W. 2 (0.9)
CF-D14 Designer hood filter for 36”W. 2 (0.9)
Model Description Approx. ship wt. lbs. (kg)
DCW24 Professional 24”W. duct cover 9 (4.0)
DCW30 Professional 30”W. duct cover 10 (4.5)
DCW36 Professional 36”W. duct cover 11 (5.0)
DCC16 Designer adjustable duct cover – for DCH 30” & 36” models 20 (9.0)
