VENTILATION

Built-In Classic Chimney Glass Wall Hood

P L A N N I N G A N D D E S I G N G U I D E

V I K I N G R A N G E . C O M

1 - 8 8 8 - V I K I N G 1

R E V I S E D 1 / 1 5 / 0 9

© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

All models include

FINISH DETAILS

• Stainless Steel (SS)

Standard Features & Accessories

Model Options

ORDERING INSTRUCTIONS

First specify model number, followed by color code (DGWH3042SS).

• Recommended for use with 30” and

36”W. non-griddle/grill ranges, 30” and
36”W. non-griddle/grill rangetops, and
30” and 36”W. cooktops

• Heavy-duty construction; sleek,

contemporary design and styling
o Virtually seamless stainless steel

design with no visible screws

• Adjustable duct cover (for 8 – 9’

ceilings) ships standard with hood

• Heat sensor turns the ventilator on full

power when cooking temperatures
reach uncomfortable levels

• Variable speed 450 CFM blower ships

standard for custom venting—allows
you to leave ventilator at favorite/most-
used setting

• May be converted for non-ducted

recirculation (accessory kit sold
separately)

• Advanced, electronic push-button

controls with LED display

• Delay feature allows you to set the

ventilator to shut off on its own

• Easy cleanup

o Dishwasher-safe, stainless steel mesh

filters efficiently remove grease and
heated vapors from the air, and are
easily removed for quick cleaning
(frame and mesh are stainless steel)

See Dimensions & Specifications
table for number of filters per model

o Design of low-profile filter system

means less interior hood space to be
cleaned

• Two 20-watt halogen lights with

dimmer control. (bulbs included)

DGWH Designer

Chimney Glass Wall Hood
