VENTILATION
Built-In Classic Chimney Wall Hood—
Standard, w/Ledge, & Ledgeless
Recommended Ventilator Kits
• See Installation Requirements table for recommendations for each hood model
• One ventilator, one duct run for any size hood/ventilator
• A 1,200 CFM interior or 1,500 CFM exterior (if applicable) ventilator should be used over ranges/rangetops with gas grill
• Must use Viking ventilator kits with Viking hoods; use of non-Viking kits voids product warranty
Duct Cover Extensions
• For use with DCWH, DCWL, & DCWN hoods
• Extends height of hood by up to 12” (for 10’ ceilings)
• Replaces adjustable duct cover supplied with hood
• Specify finish code following accessory model number (for example, DCCE1010-SS)
• Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint Julep (MJ),
Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR), Burgundy (BU), Plum
(PL), Chocolate (CH), and Cobalt Blue (CB).
Backsplashes
• Stainless Steel (SS)
• 30”H.
• Backsplashes protect the wall space below hood
• Create a continuous finish between cooking surface and hood
• Low maintenance, easy to clean
• Hemmed edges with screw holes
• Kit includes backsplash and fastening screws
✪ Installation Notes & Accessories
Kit model Description Hood models Approx. ship wt. lbs. (kg)
DIV300 300 CFM interior-power DCWH3042/3644, DCWL3342/3944, & 15 (6.8)
DCWN3042/3644
DIV440 440 CFM interior-power DCWH3042, DCWL3342, & DCWN3042 25 (11.3)
DIV600 600 CFM interior-power DCWH3644/4244, DCWL3944/4544, & 27 (12.2)
DCWN3644/4244
DIV1200 1,200 CFM interior-power DCWH4844, DCWN5144, & DCWN4844 43 (19.4)
DEV900 900 CFM exterior-power DCWH3042/3642/4244, DCWL3342/3944/4544, & 39 (17.6)
DCWN3042/3644/4244
DEV1200 1,200 CFM exterior-power DCWH3042/3644/4244/4844, DCWL3342/3944/ 53 (23.9)
4544/5144, & DCWN3042/3644/4244/4844
DEV1500 1,500 CFM exterior-power DCWH4844, DCWL5144, & DCWN4844 47 (21.3)
DIL900 900 CFM in-line power DCWH3042/3642/4244, DCWL3342/3944/4544, & 20 (9.1)
DCWN3042/3644/4244
DIL1200 1,200 CFM in-line power DCWH3042/3644/4244/4844, DCWL3342/3944/ 25 (11.3)
4544/5144, & DCWN3042/3644/4244/4844
Model Description Approx. ship wt. lbs. (kg)
DCCE1010 Duct cover extension (for 30” & 33”W. hoods—10”W. x 12”D. x 30” – 42”H.) 4 (1.8)
DCCE1210 Duct cover extension (for 30”, 39”, 42”, & 45”W. hoods—12”W. x 12”D. x 28” – 40”H.) 6 (2.7)
DCCE1810 Duct cover extension (for 48” & 51”W. hoods—18”W. x 12”D. x 28” – 40”H.) 8 (3.6)
Model Description Approx. ship wt. lbs. (kg)
BKS30 30”W. backsplash 7 (3.2)
BKS36 36”W. backsplash 9 (4.1
BKS42 42”W. backsplash 12 (5.4)
BKS48 48”W. backsplash 14 (6.3)
BKS54 54”W. backsplash 17 (7.7)
