VENTILATION
Built-In Classic Chimney Wall Hood—
Standard, w/Ledge, & Ledgeless
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
30”
min
.
(76.2
cm
) to 36”
max
.
(91.4
cm
)
66”
min
.
(167
.6 c
m) to 72”
max
.
(182
.9 c
m)
36
”
(91
.4
cm
)
30”
min
.
(76.2
cm
) to 36”
max
.
(91.4
cm
)
66”
min
.
(167
.6 c
m) to 72”
max
.
(182
.9 c
m)
36
”
(91
.4
cm
)
Dimensions & Specifications
CLEARANCE DIMENSIONS
CHIMNEY WALL HOOD
CHIMNEY WALL HOOD
LEDGE/LEDGELESS
Note: For best performance and safe, efficient operation,
it is recommended that the bottom of the hood be 30”
(76.2 cm) to 33” (83.8 cm) above the countertop.
R E V I S E D 5 / 2 / 1 1
