ViewSonic N4200w 6
Reloca ting the Sat ellite Speakers
To replace the speakers attached to LCD TV or extend the cable please contact ViewSonic or
your local distributor for advice.
To detach the satellite (side) speakers from the main LCD TV unit, please read the following
guidelines:
1. Disconnect the power to LCD TV.
2. Now remove the audio cable from
the LCD TV.
3. Set the LCD TV on a table or work
surface, screen-down with a towel or
woolen blanket between the screen
and the surface to protect the
display.
4. Remove the 6 screws holding the
speaker (3 screws on each side) to
the main unit.
5. Pull the speaker outwards, and away
from the main unit.
To connect the audio cable from a speaker to the LCD TV, ensure the polarity is correct. I.e.
match the red (+ve) wire to the red (+ve) terminal, and the black (-ve) wire to the black (-ve)
terminal connector on the LCD TV rear panel.
