Connect video cable to the output jack on the video source, and the S-video input jack on the
LCD TV.
Now connect the audio cables to the left and right audio-out terminals on the video
source to the audio-in terminals.
YCbCr / YPbPr model:
Connect video cables to the Y, Pb/Cb, Pr/Cr outputs on the video source, and the Y, Pb/Cb,
Pr/Cr inputs on the LCD TV. Now connect the audio cables to the left and right audio-out
terminals on the video source to the audio-in terminals.
S-Video Cable
(Cable not supplied)
Audio in Cable
(Cable not supplied)
VCR
Audio in Cable
(Cable not supplied)
DVD Player or VCR
YCbCr / YPbPr Cable
(Cable not supplied)
