Model NO : VS10461
Headquarters:
381 Brea Canyon Road, Walnut, CA91789, U.S.A
Tel:(800)888-8583 (909)444-8888
Fax:(909)839-7922
E-mail:[email protected]
www.viewsonic.com
Specifications subject to change without notice. Selection, offers, warranties and programs may vary by country; see your ViewSonic
representative for complete details.
PJ862
Asia Pacific:
9F, No. 192 Lien Chien Road, Chung
Ho, Taipei, R.O.C
Tel:886-2-2246-3456
Fax:886-2-8242-3666
www.viewsonic.com.tw
PJ862_En_050222
LCD
DISPLAY
AUDIO
INPUT SIGNAL
COMPATIBILITY
CONNECTOR
POWER
Language
USER CONTROLS
OPERATING
DIMENSIONS
(W x D x H)
WEIGHT
REGULATIONS
WARRANTY
Type
Resolution
Support Resolution
Lens
Size
Throw Distance
Lamp
Brightness
Contrast Ratio
Keystone Correction
Aspect Ratio
Speakers
RGB
Video
HDTV
Frequency
PC
Mac
RGB Input
RGB Output
Digital Input
Composite Video
S-Video
Component Video
Audio Input
Audio Output
Control
USB
Voltage
Consumption
Control Panel
Remote
OSD
Temperature
Humidity
Physical
ViewSonic PJ862 Project ViewSonic PJ862 Project
Horizontal and Vertical Keystone
Correction
Square your image from any angle
Ultimate Flexibility with Multiple
RGB Inputs
Connect two computers simultaneously or
add a video source for dynamic meetings.
Built-in DVI Digital Connnector
It is perfect to use digital signal via DVI
connector in digital projector. The image can
be sure no decay in signal to present perfect
color and detail.
Displays HDTV Signals
ViewSonic projectors project a wide variety
of content which including HDTV signals
(480i, 480p, 576p, 720p and 1080i)
Built-in Progressive Scanning
The function satisfies the requirements of
local digital television systems and global
satellite programming. The superb visual
quality of HDTV programs is displayed to the
fullest.
3D Comb Filter
Use unique 3D digital comb filter technology
with a three dimensional format to eliminate
interference and effectively protect against
signal degradation. The 3D digital comb filter
maintains the integrity of the original signal.
Advanced Video Features
Progressive scan and 3:2 pull down for
superior video performance.
Network Control
Remote management of projector controls
and diagnostics.
Full Functions Wireless Remote
Control
The handy remote control is perfectly
matching for mobile presentations. Plus the
built-in presentation functions enable the
versatility.
Whisper-Mode
Whisper-mode allows the user to operate
the projector at two settings - "normal" for
maximum performance and "whisper" for
low noise levels plus extended lamp life.
Easy Setup and Auto Tuning
One-touch setup button for fast, easy sync
and sharp focus.
Best Service & Support
At ViewSonic, we are devoted to customer
satisfaction.
We strive constantly to
understand your interests and concerns, and
treat you with respect, courtesy and
consideration. For the warranty information,
please
contact your local ViewSonic
distributor or ViewSonic service center.
0.79" inches (x3) Poly-Si TFT with Micro Lens
XGA 1024x768
1600x1200 (compressed)
Manual zoom/focus (1:1.2x)
30"-300" (Diagonal)
0.9m-9.2m (2.95ft-30.18ft)
230 watt UHB
3200 Lumens
400:1
Vertical Digital keystone correction: +/- 15degrees
Horizontal Digital keysomecorrects: +/- 15 degrees
4:3 & 16:9
3w x 2 Stereo
RGB analog
NTSC, PAL, SECAM
HDTV (480i, 480p, 576p, 720p, 1080i)
Fh:15-91 KHz, Fv:50-120 Hz
VGA to UXGA
Up to SXGA (may require Mac Adapter)
15-pin HD D-sub (x2)
15-pin HD D-sub (x1)
DVI (x1)
RCA Jack (x1)
Mini-Din 4 pin (x1)
RCA Jack (x1 set for YCbCr/YPbPr)
3.5 mm Stereo Mini Jack (x2) for RGB , RCA (L/R) Jack (x1) for Video
3.5 mm Stereo Mini Jack (x1)
RS-232 (9 Pin D-sub) x1
x1
100~120VAC/200~240VAC(Auto Switching), 50/60Hz (universal)
330W (Typical)
English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese,
Portuguese, Shimplified Chinese, Korean, Swedish, Russian, Finnish, Polish.
Standby/On, Temp, Lamp, Volume, Input, Search, M1-D, RGB, BNC, Component, S-
Video, Video, Zoom, Focus, Keystone, Menu, Reset, Enter, Cursor
Standby/On, Search, Zoom, Focus, Keystone, Menu, Reset, Enter, Cursor, Laser
indicator, Video, RGB, Blank, Aspect, Laser, ESC, Position, Auto, PinP, Magnify,
Freeze, Volume, Mute, ID change switch
Main: Bright, Contrast, Aspect, Whisper, Mirror, Language, Reset
Picture-1: Gamma, Color Bal R, Color Bal G, Color Bal B, Sharpness, Color, Tint, My
Memory, Reset
Picture-2: V Position, H Position, H Phase, H Size, Over Scan, Reset
Input: Color Space, Component, Video, 3D-YCS, Video NR, P.IN P. Input, P. IN P. Posit,
Powerup Input, Information, S2-Aspect
Auto: Adjust, Power Off, Power On, Search, Reset
Screen: Blank, Start Up, MyScreen, MyScreen Size, MyScreen Lock, Menu Position,
Message, Reset
Option: Volume, Speaker, IR Remote, IR Remote ID, Lamp Time, Filter Time,
Service, Reset
Network: Setup, DHCP, Information, Reset"
0 C-35 C (32 F-95 F)
10%-85% (non-condensing)
336mm x 265mm x 95mm
13.2" x 10.4" x 3.7"
4 kgs (8.87 lbs)
UL60950/C-UL,FCC B, TUV/GS, CB, CE, C-Tick, GOST, NOM, CCC, and PSB
3 years
