VXI VT1433B User Manual
Page 142
Pin definitions for input connector
definition
pin #
pin #
definition
RFI GND/Cable Shield
26
13
- Diff 1
+24V Power
25
12
+Diff 1
GND Return for ± 24V
24
11
RFI GND/Drain Shield 1
-24 Power
23
10
RFI GND/Drain Shield 2
RFI GND
22
9
- Diff 2
I2C SCL
21
8
+ Diff 2
CAL HIGH
20
7
CAL LOW
BoB_EN
19
6
- Diff 3
RFI GND
18
5
+ Diff 3
I2C SDA
17
4
RFI GND/Drain Shield 3
RFI GND
16
3
RFI GND/Drain Shield 4
I2C_EN
15
2
- Diff 4
RFI GND/Cable Shield
14
1
+ Diff 4
VT1433B User's Guide
Break Out Boxes
8-6
pin 26
pin 13
pin 14
pin 1
COLA
Out
Shut
Fail Acs
Source
Chan
1-4
Chan
5-8
8-CHANNEL 196
+DSP
kSa/s DIGITIZER
VT1433B
