Page 75: Pre l iminar y
Vidikron PlasmaView VHD Installation/Operation Manual
63
PRE
L
IMINAR
Y
7.3
PlasmaView VHD
Dimensions
Figure 7-1, Figure 7-2 and Figure 7-3 show the PlasmaView VHD dimensions (all dimensions
are in inches).
Figure 7-1. PlasmaView VHD Model VP-5000VHD Dimensions (with Optional Table
Stand)
0.9
1.3
2.5
50.4
29.2
32.4
48.4
14.0
31.5
20.5
2.1
6.9
11.5
12.6
26.0
