Vidikron PlasmaView VHD Installation/Operation Manual 5
PRE
L
IMINAR
Y
2.1
PlasmaView VHD at a
Glance
Controls and Indicators Figure 2-1, Figure 2-2 and Figure 2-3 show the PlasmaView VHD front-panel controls and
indicators.
Figure 2-1. PlasmaView VP-5000VHD Front-Panel Controls and Indicators
Figure 2-2. PlasmaView VP-6500VHD Front-Panel Controls and Indicators
2
Controls and Functions
1
3
2 (behind
front bezel) 4
1
2
3 4
(behind
front bezel)
