Page 42: Pre l iminar y
30
Vidikron PlasmaView VHD Installation/Operation Manual
PRE
L
IMINAR
Y
Connecting AC Power
Plug the female end of the power cord into the AC receptacle on the rear of the PlasmaView
VHD. Connect the other end to your AC power source. (The VP-103VHD requires
200 – 240 VAC.)
Figure 3-13. AC Power Connection
Similarly connect the VHD Controller to a nearby AC outlet.
➤
VP-5000VHD
VP-6500VHD
VP-103VHD (NOTE: The VP-103VHD requires 200 - 240 VAC)
