20
Vidikron PlasmaView VHD Installation/Operation Manual
PRE
L
IMINAR
Y
Figure 3-2. Ventilation Requirements for Enclosure Mounting (VP-5000VHD and
VP-6500VHD)
Figure 3-3. Ventilation Requirements for Enclosure Mounting (VP-103VHD)
50
mm
(2")
50
mm
(2")
50
mm
(2")
Wall
Wall
50
mm
(2")
50
mm
(2")
300mm
(11.8")
Wall
Wall
200mm
(7.87")
300mm
(11.8")
300mm
(11.8")
300mm
(11.8")
