Vox Pedal User Manual
Page 6
6
3.
Output
: This is the 1/4" output. Plug a second guitar cable between this and
your amp, or between this and the next pedal in your chain. Use this output
when running the Time Machine in mono.
4.
Delay Range:
This four-position knob selects the delay range, from four
ranges—125ms, 250ms, 500ms, and 1000ms. This control enables you to very pre-
cisely set the delay time on this pedal. After you set the desired delay range, use
the Time knob to “fine tune” the delay time within the selected range. Delay
ranges are as follows:
When the time parameter is set by using
the tap tempo switch, this knob indi-
cates the rate of the note as follows:
(The time set by the Tap Tempo switch is
1/4.)
TIME knob Range
125ms:
0ms–125ms
250ms:
125ms–250ms
500ms:
250ms–500ms
1000ms:
500ms–1000ms
250ms:
1/8
125ms:
1/12
500ms:
3/16
1000ms:
1/4
