Controls
Note: Always turn off your guitar amplifier before you connect your guitar cables,
power supply cables, or change the battery in your Time Machine, to avoid dam-
aging your amp.
1. AC adapter jack : This allows for connection to an optional 9V DC power supply
(not included).
2. Level: This knob controls the overall level of the delay effect. Turn this knob
clockwise to increase the mix of the delay effect with the guitar signal. Turn this
knob counter-clockwise to decrease the mix and reduce the amount of delay
effect.
