VX-8R O
PERATING
M
ANUAL
3
D
ISPLAY
I
CONS
& I
NDICATORS
c F
REQUENCY
C
ONTROL
VFO: VFO Mode
MR: Memory Mode
MT:
Memory Tune Mode
HOM: Home Channel Memory
PMS: Programmable Memory Scan Mode
VDW: Dual Watch Active
(VFO-Memory Channel)
MDW:Dual Watch Active
(Memory Channel-Memory Channel)
h S
QUELCH
T
YPE
& R
ADIO
M
ODE
TN: Tone Encoder Active
TSQ: Tone Squelch Active
DCS: Digital Code Squelch Active
RTN: Reverse Tone Squelch Active
PR:
User Programmed Reverse CTCSS Decoder Active
PAG: Enhanced Paging & Code Squelch (EPCS) Active
MSG: Message Feature Active
DC:
Split Tone Feature Active (DCS Encode only)
T-D: Split Tone Feature Active (Encodes a CTCSS Tone and Decodes a DCS Code)
D-T: Split Tone Feature Active (Encodes a DCS Code and Decodes a CTCSS Tone)
A12: APRS ® Feature Active (1200 bps)
A96: APRS ® Feature Active (9600 bps)
: AM/FM Broadcast Reception
i M
ISCELLANEOUS
S
ETTING
: Repeater Shift Direction (Minus Shift)
: Repeater Shift Direction (Plus Shift)
: Independent Transmit Frequencies
(Odd Splits)
: Attenuator Active
: Bell Alarm Active
: Receiving an FM Stereo Signal
j O
PERATING
M
ODE
NFM: FM
WFM: Wide FM
AM: AM
“A” Band
Display
“B” Band
Display
Icon
h
i
j
h
i
j
c d e f g
e d c f g
d V
OLUME
L
EVEL
e TX P
OWER
L
EVEL
HI: High Power (5 W)
L3: LOW3 Power (2.5 W)
L2: LOW2 Power (1 W)
L1: LOW1 Power (0.5 W)
f O
PERATING
F
REQUENCY
g S&PO M
ETER
I
CON
: Secondary Keypad Active
: Internet Connection Feature (WiRES TM ) Active
: DTMF Autodialer Active
: Emergency Automatic ID (EAI) Feature Active
: Automatic Power-Off Active
: Bluetooth ® Active
: Key Lock Active
: Mute Feature Active
: VOX Feature Active
: Battery Saver Active
: Battery Indicator
