VX-8R O

PERATING

ANUAL

157

ODE

TEM

91: SPEC-ANALYZER

Function: Selects the Spectrum Analyzer sweep mode.
Available Values: 1Time / CONTINUOUS / Full Time
Default: 1time
1Time:

The receiver sweeps the current band once.

CONTINUOUS: The receiver sweeps the current band repeatedly until the Spectrum Ana-

lyzer is turned off.

Full Time:

This mode is activated similar to a “Continuous” mode. However, the
transceiver outputs audio on the center frequency (T) through the speaker
when Spectrum Analyzer is activated.

ODE

TEM

92: SQL LEVEL

Function: Sets the Squelch threshold level.
Available Values: LEVEL 0 ~ LEVEL 15 (AM and Narrow FM), LEVEL 0 ~ LEVEL 15
(Wide FM and AM Broadcast)
Default: LEVEL 1 (AM and Narrow FM), LEVEL 2 (Wide FM and AM Broadcast)

ODE

TEM

93: SQL S-METER

Function: Adjusts the Squelch threshold level to the S-meter level.
Available Values: OFF / LEVEL 1 ~ LEVEL 9
Default: OFF

ODE

TEM

94: SQL SPLIT

Function: Enables/Disables split CTCSS/DCS coding.
Available Values: OFF / ON
Default: OFF
When this Set Mode Item is set to “ON”, you can see the following additional parameters
after the “MESSAGE” parameter while selecting the Set Mode Item 97: SQL TYPE:
D CD:

DCS Encode only (“DC” icon will appear while operating)

TONE-DCS:

Encodes a CTCSS Tone and Decodes a DCS code
(the “T-D” icon will appear during operation)

D CD-TONE SQL: Encodes a DCS code and Decodes a CTCSS Tone

(the “D-T” icon will appear during operation)

Select the desired operating mode from the selections shown above.

ODE

ELECTION

ETAILS
