53
W
all Mounting the Base
(To AC outlet)
Wall plate
Removing the wall-mount bracket
At the bottom of the base,
pinch the two "nose" of
the wall-mount bracket
as shown, and then
slide the bracket away
from the base.
Place the mounting slots over
the pins on the wall plate.
Slide the base
down to lock it
into place.
Note: Mounting the phone directly on the wall
Be sure the wall is capable of supporting the
weight of the phone, and use the proper type of
anchoring device for the wall material.
Insert two #10 screws (minimum length of 35mm
, not supplied) into the wall, 100mm apart.
Leave the screw heads 3mm away from the wall
to allow room for mounting the phone.
Align the mounting slots over the screws and
slide the base down into place as shown above.
•
•
•
•
