Uniden MHS050-2 - Manual (Page 19)

E-19 Uniden MHS050-2 Owner’s Manual
Power Source
Rechargeable NiMH Battery Pack
4.8 V 700 mAh
Size (without antenna)
8.98 (H) x 2.52 (W) x 1.54 (D) inch
228 (H) x 64 (W) x 39 (D) mm
Weight 8.53 oz (242g) (w/battery and antenna)
Transmitter
Frequency Range 156 ~ 158 MHz
Frequency Stability ±2.5 PPM
Power Output 1.0 W and 2.5 W
Spurious Emissions -34 dBm on Hi; -39 dBm on Lo
Current Drain 1100 mA (2.5 W)
Receiver
Type
Double Conversion Super Heterodyne
Phase Locked Loop system for Local
Oscillator
Frequency Range 156 ~ 162 MHz
Sensitivity 0.20 μV for 12 dB SINAD
Squelch Sensitivity Threshold 0.12 μV
Audio Frequency
Response
+6 dB @ 500 Hz; -6 dB @ 2000 Hz
Adjacent Channel
Selectivity
70 dB @ ±25 kHz
Audio Output Power 0.16 W @10% THD
Current Drain Squelched: 55 mA; Max. Audio: 175 mA
