4-9 ASUS T5-P5G41E
4.2.4 Menu items
The highlighted item on the menu bar displays the specific items for that menu.
For example, selecting Main shows the Main menu items.
The other items (Advanced, Power, Boot, and Exit) on the menu bar have their
respective menu items.
4.2.5 Sub-menu items
A solid triangle before each item on any menu screen means that the iteam has a
sub-menu. To display the sub-menu, select the item and press .
4.2.6 Configuration fields
These fields show the values for the menu items. If an item is user-configurable,
you can change the value of the field opposite the item. You cannot select an item
that is not user-configurable.
A configurable field is enclosed in brackets, and is highlighted when selected. To
change the value of a field, select it then press to display a list of options.
Refer to 4.2.7 Pop-up window.
4.2.9 General help
At the top right corner of the menu screen is a brief description of the selected
item.
Some of the navigation keys differ from one screen to another.
4.2.7 Pop-up window
Select a menu item then press
to display a pop-up
window with the configuration
options for that item.
4.2.8 Scroll bar
A scroll bar appears on the right
side of a menu screen when
there are items that do not fit on
the screen. Press the
Up/Down arrow keys or
Up> / keys to display the other items on the screen.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Advanced Power Boot Tools Exit
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system
Time.
System Time [ 19 :34:30]
System Date [Wed 08/27/2008]
Legacy Diskette A [1.44M, 3.5 in.]
Primary IDE Master :[Not Detected]
Primary IDE Slave :[Not Detected]
SATA1 :[Not Detected
SATA2 :[Not Detected]
SATA3 :[Not Detected]
SATA4 :[Not Detected]
Storage Configuration
System Information
Options
Disabled
360K, 5.25 in.
1.2M, 5.25 in.
720K, 3.5 in.
1.44M, 3.5 in.
2.88M, 3.5 in.
Pop-up window
