66
4.3 Phoenix BIOS Post Code
Code Beeps / Description Code Beeps / Description
02h Verify Real Mode 32h Test CPU bus-clock
frequency
03h Disable Non-Maskable
Interrupt (NMI)
33h Initialize Phoenix Dispatch
Manager
04h Get CPU type 36h Warm start shut down
06h Initialize system hardware 38h Shadow system BIOS ROM
08h Initialize chipset with initial
POST values
3Ah Autosize cache
09h Set IN POST flag 3Ch Advanced configuration of
chipset registers
0Ah Initialize CPU registers 3Dh Load alternate registers with
CMOS values
0Bh Enable CPU cache 42h Initialize interrupt vectors
0Ch Initialize caches to initial
POST values
45h POST device initialization
0Eh Initialize I/O component 46h 2-1-2-3. Check ROM
copyright notice
0Fh Initialize the local bus IDE 48h Check video configuration
against CMOS
10h Initialize Power
Management
49h Initialize PCI bus and
devices
11h Load alternate registers with
initial POST values
4Ah Initialize all video adapters
in system
12h Restore CPU control word
during warm boot
4Bh QuietBoot start (optional)
13h Initialize PCI Bus Mastering
devices
4Ch Shadow video BIOS ROM
14h Initialize keyboard controller 4Eh Display BIOS copyright
notice
16h 1-2-2-3. BIOS ROM
checksum
50h Display CPU type and
speed
17h Initialize cache before
memory autosize
51h Initialize EISA board
18h 8254 timer initialization 52h Test keyboard
1Ah 8237 DMA controller
initialization
54h Set key click if enabled
1Ch Reset Programmable
Interrupt Controller
58h 2-2-3-1. Test for
unexpected interrupts
20h 1-3-1-1. Test DRAM refresh 59h Initialize POST display
service
22h 1-3-1-3. Test 8742 KBD
Controller
5Ah Display prompt "Press F2 to
enter SETUP"
24h Set ES segment register to
4 GB
5Bh Disable CPU cache
26h Enable A20 line 5Ch Test RAM between 512 and
640 KB
28h Autosize DRAM 60h Test extended memory
29h Initialize POST Memory
Manager
62h Test extended memory
address lines
2Ah Clear 512 KB base RAM 64h Jump to UserPatch1
2Ch 1-3-4-1. RAM failure on
address
66h Configure advanced cache
registers
2Eh 1-3-4-3. RAM failure on
data bits of low byte of
67h Initialize Multi Processor
APIC
