48
3.4.1.2.1 PCI-E1 Sub-Menu
PhoenixBIOS Setup Utility
Main Advanced Security Power Boot Exit
PEI-E1 Sub-Menu
Item Specific Help
PCI Express Graphics Port [Auto]
-------------------------------------------------------------------------
PEG Enabled
PEG Number
PEG Width
--------------------------------------------------------------------------
PEG Slot Number
PEG Power Limit
PEG Slot Card Detect
Disabled --- Port always
disabled.
Enabled --- Port always
enabled.
Auto --- Only enable if
card found.
Debug --- only enable if
card found. Don’t force
link width.
F1 Help ↑↓ Select Item -/+ Change Values F9 Setup Defaults
Esc Exit ← → Select Menu Enter Select X Sub-Menu F10 Save and Exit
PCI Express Graphics Port
This feature is used to control the PCI Express Graphics port.
Options: Auto / Enabled / Disabled / Debug
PEG Enabled / PEG Number / PEG Width / PEG Slot Number / PEG Power
Limit / PEG Slot Card Detect
Read only.
