54
3.4.5 Hardware Monitor
This section allows you to fine tune the Hardware Monitor configuration.
PhoenixBIOS Setup Utility
Main Advanced Security Power Boot Exit
Hardware Monitor
Item Specific Help
X
Voltage Monitoring
CPU FAN1
FAN2
FAN3
FAN4
FAN5
FAN6
CPU Temp.
Ambient1 Temp.
Ambient2 Temp.
FAN Fail LED Indicator
Auto FAN Control
[Disabled]
[Disabled]
F1 Help ↑↓ Select Item -/+ Change Values F9 Setup Defaults
Esc Exit ← → Select Menu Enter Select X Sub-Menu F10 Previous Values
CPU FAN1/FAN2/FAN3/FAN4/FAN5/FAN6/CPU Temp./Ambient1 Temp./
Ambient2 Temp.
Items can not be modified in user mode. Read only.
FAN Fail LED Indicator
When it is set to [Enabled], the LED will be on when the FAN failed.
Options: Disabled / Enabled
Auto Fan Control:
This feature is used to set function of Auto Mode Fan Control.
Options: Enabled / Disabled
