APPENDIX A: TECHNICAL SPECIFICATIONS
TA-500 TA-500t TA-500H TA-500HM
Dimensions
mm (inches) 977 x 574 x 498
(38.5 x 22.6 x 19.6) 977 x 574 x 498
(38.5 x 22.6 x 19.6) 551 x 983 x 498
(22.6 x 55.1 x 30.3) 551 x 574 x 498
(21.7 x 22.6 x 19.6)
Net weight 52kg (114.4lbs) 57kg (125.4lbs) 52kg (114.4lbs) 37kg (81.4lbs)
Frequency range
(±4dB) 60Hz – 20kHz 60Hz – 20kHz 60Hz – 20kHz 250Hz – 20kHz
Dispersion 50°H x 25°V 50°H x 25°V 50°H x 25°V 50°H x 25°V
Power handling
(continuous) LF: 400 watts
MF: 200 watts
HF: 50 watts LF: 400 watts
MF: 200 watts
HF: 50 watts LF: 400 watts
MF: 200 watts
HF: 50 watts MF: 200 watts
HF: 50 watts
Sensitivity (1w@1m) LF: 106dB
MF: 105dB
HF: 112dB LF: 106dB
MF: 105dB
HF: 112dB LF: 106dB
MF: 105dB
HF: 112dB MF: 105dB
HF: 112dB
Max SPL (max/cont) 135dB/141dB 135dB/141dB 135dB/141dB 132dB/136dB
Crossover points Passive: 250Hz
Active: 250Hz,
4k/5k99Hz Passive: 250Hz
Active: 250Hz,
4k/5k99Hz Passive: 250Hz
Active: 250Hz,
4k/5k99Hz 4k/5k99Hz
Nominal impedance LF: 8 ohms
MF: 16 ohms
HF: 16 ohms LF: 8 ohms
MF: 16 ohms
HF: 16 ohms LF: 8 ohms
MF: 16 ohms
HF: 16 ohms MF: 16 ohms
HF: 16 ohms
Construction 15mm & 18mm
birch plywood 15mm & 18mm
birch plywood 15mm birch
plywood 15mm birch
plywood
Connectors 2 x NL8MP
1 x NL4MP 2 x NL8MP
1 x NL4MP 2 x NL8MP
1 x NL4MP 3 x NL8MP
