Connecting Flying Chains to the Cabinet

The bolt slides back along its runner enabling the placing of the profile into the slot. The bolt
is spring loaded to ensure that when in its closed position (as shown below) it is free from
vibration and cannot be damaged.

Figure 4: Locking Mechanism

Bolt

Slot
