The net weight of the bar is 21kg and the SWL is 380kg.
PICKUP POINT
(NARROW)
TILT STRAP POINT
PICKUP POINT
(WIDE AND SINGLE)
ENCLOSURE LIFT
POINT (WIDE)
ENCLOSURE LIFT
POINT (NARROW)
ENCLOSURE LIFT
POINT (SINGLE)
TOP VIEW
BOTTOM VIEW
Figure 1: FB-500T/2W Touring Two-wide Flybar
Figure 2: Flybar Lifting Points and Dimensions
Two columns of enclures can be flown from the FB-500T/2W flybar. Additionally a single
column facility is provided allowing the flying of a single column of enclosures.
