Lifting the column

When ALL the chains have been connected and the biscuit has been interlocked, the column

is ready for lifting. Using the appropriate lifting point on the flybar, attach the bridle and lift
ensuring during the lifting process that the column lifts evenly.

Figure 10: Front view of the assembled cluster

Figure 11: Rear view of the assembled cluster
