Self-powered Enclosures
Model NuQ-8DP NuQ-10DP NuQ-12DP NuQ-15DP B15DP B18DP
Dimensions
HxWxD 464x272x252
18.3x10.7x9.9
525x318x281
20.7x12.5x11.1
655x373x340
25.8x14.7x13.4
712x430x385
28x16.9x15.2 464x574x620
18.3x22.6x24.4
768x574x700
30.2x22.6x27.6
Net Weight 13kg
(28.6lbs)
15.5kg
(34.1lbs)
23kg
(50.6lbs)
29kg
(63.8lbs)
39kg
(85.8lbs)
67.5kg
(148.5lbs)
LF driver 1 x 8”
(203mm)
1 x 10”
(254mm)
1 x 12”
(305mm)
1 x 15”
(381mm)
1 x 15”
(381mm)
1 x 18”
(457mm)
HF compression
driver 1 x 1” (25mm) 1 x 1.4” (35mm) n/a
Frequency
Response ±4dB 60Hz - 20kHz 55Hz - 20kHz 55Hz - 20kHz 50Hz - 20kHz 45Hz – 120Hz 40Hz - 150Hz
Nominal
Dispersion
@-6dB points 100°H x 60°V 80°H x 50°V n/a
Maximum SPL
continuous->
peak-> 118dB
124dB 121dB
127dB 127dB
133dB 129dB
135dB 126dB
132dB 130dB
136dB
Construction 12mm (1/2”) birch plywood 15mm (5/8”) birch plywood 18mm (3/4”) birch plywood
Amplifier Class D
Power Output 500 watts @ 8 ohms 2 x 800 watts @ 8 ohms
Dynamic Range 110dB
Input clip 10dBu
Bandwidth 20Hz – 20kHz (±0.5dB)
Grille Powder coated perforated steel mesh, backed with black reticulated foam
Power
Requirements 100v to 230v AC, 50-60Hz
Connectors Input: (1) XLR female, Link: (1) XLR male, wired pin 2 hot, (1) Neutrik Powercon mains, (2) RJ45 network ports
Finishes Black semi-matt textured paint, optional white textured paint
Technical Specification Notes:
Frequency response is measured on axis. Nominal Dispersion and sensitivity are an average over
stated bandwidth. Maximum continuous SPL is measured by using unweighted diode-clipped pink
noise in a half space environment. Maximum peak SPL is verified by subjective listening tests of
familiar program material, before the onset of perceived signal degradation
NB: Due to continuing product improvement these specifications are subject to change.
