Technical Specifications
Non-Powered Enclosures
Model NuQ-8 NuQ-10 NuQ-12 NuQ-15 B15 B18
Dimensions
HxWxD
mm (inches) 464x272x220
18.3x10.7x8.7
525x318x258
20.7x12.5x10.2
655x373x340
25.8x14.7x13.4
712x430x385
28x16.9x15.2 464x574x620
18.3x22.6x24.4
768x574x700
30.2x22.6x27.6
Net Weight 9.5kg (20.9lbs) 12kg (26.4lbs) 20kg (44lbs) 26kg (57.2lbs) 36.5kg(80.3lbs) 65kg (143lbs)
LF driver 1 x 8”
(203mm)
1 x 10”
(254mm)
1 x 12”
(305mm)
1 x 15”
(381mm)
1 x 15”
(381mm)
1 x 18”
(457mm)
HF compression
driver 1 x 1” (25mm) 1 x 1.4” (35mm) n/a
Frequency
Response ±4dB 60Hz - 20kHz 55Hz - 20kHz 55Hz - 20kHz 50Hz - 20kHz 45Hz - 120Hz 40Hz - 150Hz
Nominal
Dispersion 100°H x 60°V @ -6dB points 80°H x 50°V @ -6dB points n/a
Power Handling
Recommended
amplifier power
@ 8 Ohms
250 watts cont.
500 watts pgm
500 watts
300 watts cont.
500 watts pgm
500 watts
450 watts cont.
900 watts pgm
900 watts
600 watts cont.
1200 watts pgm
1200 watts
400 watts cont.
800 watts pgm
800 watts
600 watts cont.
1200 watts pgm
1200 watts
Sensitivity
1 watt @ 1
metre 94dB 96dB 98dB 100dB 100dB 102dB
Max SPL
continuous->
peak-> 118dB
124dB 121dB
127dB 127dB
133dB 129dB
135dB 126dB
132dB 130dB
136dB
Crossover
2k5Hz 1k6Hz 12dB/octave low-pass at 150Hz
Nominal
Impedance 8 ohms
Construction 12mm (1/2”) birch plywood 15mm (5/8”) birch plywood 18mm (3/4”) birch plywood
Grille Powder coated perforated steel mesh, backed with black reticulated foam
Connectors (2) Neutrik Speakon NL4MP wired
pin1+: positive, pin 1-: negative,
pins 2+ and 2- N/C
(2) Neutrik Speakon NL4MP wired
(passive) pin1+: positive, pin 1-:
negative, pins 2+ and 2- N/C, wired
(active) pin1+: LF positive, pin 1-: LF
negative, pin2+: HF positive, pin2-:
HF negative
(2) Neutrik Speakon NL4MP wired
pin1+: positive, pin 1-: negative,
pins 2+ and 2- N/C
Finishes Black semi-matt textured paint, optional white textured paint
Note: All two-way models feature a rotatable Converging Elliptical Waveguide™ which
can be rotated through 90° in the cabinet.
