1.Product Assembly and Components
Printer Paper
Paper Width 58mm
Paper Roll Diameter Maximum 55mm
a Product Structure
Please verify that the following components are in the package.
Instruction Manual
(Technical Notes)
Bottom Cover
Accessories
a Rear View of Control Box
Column Attachment
Screws
Bottom Cover
Attachment Screws
ቢ Paper Dispenser Cover
ባ Printer Cover
ቤ Control Panel
ብ Digital Display
ቦ Left-hand grip
ቧ Right-hand grip
ቨ Column
ቩ Anterior Electrodes
ቪ Posterior Electrodes
ቫ Level Gauge
ቭ Adjustable feet
ቢ
ቨ
ቧ
ቦ
ቩ
ባ
ቤ
ቪ
ቫ
Control Box
AC Adapter
cable
Platform
ብ
ቭ
RS-232C
RS-232C Port
a Digital Display
CLOTHES
ATHLETIC
MALE
WEIGHT
FEMALE
STEP ON
kg
cm
ft.in
AGE
% FAT
lb
Body weight mark
Indicates that the device is being
used to measure body weight
Clothes weight mark
Indicates that the weight of
clothes is being subtracted
Gender mark (male)
Indicates that the user is male
Gender mark (female)
Indicates that the user is female
Athlete mark
Indicates that the user is an
“athlete”
Ready mark
Indicates that the device is
ready to begin measurements
Measurement unit mark (kg)
Indicates that the weight is
shown in kilograms
Measurement unit mark (lb)
Indicates that the weight is
shown in pounds
Unit of height (cm)
Indicates that the height is
shown in centimeters
Unit of height (ft. in)
Indicates that the height is
shown in feet and inches
Age mark
Indicates that the figure shown
is the user’s age
Body fat percentage
Indicates that the figure shown
is the body fat percentage
