8.11 BASIC MENU STRUCTURE
Table 8-4 illustrates the basic P7200 and P5200 OpenSky menu structure. Menu items will vary
depending upon system programming, radio hardware, and optional configurations. All menus except the
dwell display menu can be turned off by network administration personnel. Scroll through available menu
options using the or buttons.
To traverse the menu options with a P7230 Select Model radio, press or to
scroll through menus. Press and hold to enter options mode. Press or to
scroll through available options using or . Press and hold to select option.
Table 8-4: Basic P7200 and P5200 OpenSky Menu Structure
MENU
NAME RADIO
DISPLAYS
USAGE NOTES
To/From Dwell
Display
Engineering
Display
bit-error rates
and RSSI data
Displays radio system connection data. For engineering use.
Silent
Emergency
“SilentEmerg” Use or to toggle between OFF/ON. Press to enable.
Operating Mode “App Mode”
Use or to choose an available mode ( OTP, OCF, or ECP) . Press and confirm
(Y/N) with or and again.
GPS Fix “GPS”
GPS latitude and longitude position of currently tuned-to base station [“GPS (Site)”] or
V-TAC (“GPS”) scrolls across top line of the display. “GPS (Aged)” indicates VTAC
coordinates haven’t been updated for more that 2 minutes.
User ID “User ID” User’s identification/name scrolls across top line of the display (if programmed).
IP Address “IP Address” Radio’s Internet Protocol (IP) address scrolls across top line of the display.
Station
Identification
“Station ID” Station’s identification/name scrolls across top line of the display (if programmed).
Stealth Mode
(display backlight
is disabled)
“StealthMenu”
Use or to turn Stealth Mode “On” or “Off.” See Section 8.17 for more
information about Stealth Mode.
Treble Level “Treble Menu”
Use or to choose speaker treble level (LOW, MEDIUM, MEDHIGH, or HIGH).
Press to return to dwell display.
Display
Brightness
“Bright Menu” Use or to brighten or dim backlighting. Press to return to dwell display.
Side Tone Level “Side Menu”
Use or to choose side tone level (OFF, LOW, MED, or HIGH). Press to
return to dwell display.
See Next Page
