MM23772, Rev. F
114
3. The radio will continue to receive and transmit normally while in the menu function.
4. To scroll through the menu options use the or keys. When the required menu item has been
found align the cursor with the option then press to select it. The menu item's parameter setting
shown in the display can now be changed by using or to scroll through the list of parameter
values.
5. Once the desired setting is reached press to store the value and return the menu option selection
level.
6. For menu items that display radio information, pressing or will scroll through a list of
informational displays. The possible menu items are in Table 11-5.
11.16.1 Menu Item Selection Process
An example of the menu item selection process and menu item parameter change is detailed below for the
backlight menu item.
1. Press to enter the menu mode.
2. Press or until the display shows:
3. Press
.
The backlight menu item is activated. Line one shows the active menu item and its current
parameter setting. Line two shows the currently selected system or group name (see Figure 11-7).
Figure 11-7: Backlight Menu Display
4. The menu item's parameter setting shown in the display can now be changed by using or .
5. Once the desired setting is reached press to store the value and return the menu option selection
level.
For menu items that display radio information, pressing or will scroll through a list of
informational displays. An example of information displays is shown in Table 11-6.
The TX POWER menu item, when selected, toggles LOW/HIGH power. It does not use
or to scroll nor is an additional press of the button required.
