PhySicAl
Size
86 x 86 x 22mm (3.4” x 3.4” x 0.87”)
Weight 222.7g (7.9oz) with connectors
Housing Flame retardant polycarbonate containing
fully encapsulated electronics.
Colour Dark Grey
Power
- Voltage
9 – 15Vdc
- Current Consumption 140mA (passive), 250mA (peak)
- Backup Battery
Rechargable Lithium battery giving
database backup for over 3 months.
Environmental
- Temperature
-10º to 50ºC (14º to 122ºF)
- Humidity 95% non condensing
LED Indicators Three high intensity LED indicators red,
amber and green
LCD Indicators Two line by 16 character supertwist LCD
with backlight
Keypad 12 character, standard layout, tactile
response keypad.
FUncTionAliTy
Inputs
Four analog inputs (Transguard protected)
(Door Position, Lock Position, REX Button,
Spare)
Outputs Two current limited open collector outputs
(Door Lock, Unused – for future use)
Memory 1 MB battery backed SRAM
Database
- Cardholders
Storage of up to 197,000 cardholders at
the door.
- Transactions Up to 50,000 transactions in offline
operation.
Configuration Operational parameters are downloaded
from host computer. Some configuration
setting can also be set using the keypad.
commUnicATion inTERFAcE
To Exit Reader
RS485 multidrop cable runs using copper
wire with maximum length of 1.2km
without repeater
- Connection 2 part screw terminals
To System Host 10 Base-T TCP/IP using CAT5 Unshielded
twisted pair Cable
- Connection RJ45
PRodUcT codES
EtherProx EPO200 (125 kHz Proximity)
SPASS-EPO-200-B
EtherProx Reader
SPASS-EPO-200-A EtherProx Reader (US Backplate)
EtherProx EPO210 (MiFare CSN)
SPASS-EPO-210-B
EtherProx Reader
SPASS-EPO-210-A EtherProx Reader (US Backplate)
CEM Systems Ltd Unit 4 Ravenhill Business Park Ravenhill Road Belfast BT6 8AW Northern Ireland
Tel: +44 (0)28 9045 6767 Fax: +44 (0)28 9045 4535 email: [email protected]
www.cemsys.com
door control Unit installation
The enclosure is designed to mount directly onto a standard
UK or European (French) electrical containment box (American
versions are provided with a compact adapter plate), meaning
that standard conduit and fittings may be used.
Remote Programming
Operational parameters, e.g. door open time, are downloaded to
the reader from the host computer. Additionally some parameters
can also be configured via the keypad. EtherProx readers can even
be remotely upgraded, eliminating the need to physically replace
firmware, giving increased system flexibility and efficiency.
card Technology
The EtherProx reader (EPO200) uses 125 kHz proximity
technology under license from HID Corporation.
A 13.5 MHz technology option (EPO210) of the reader is available
enabling the EtherProx to read the unique ID of MiFare smart
cards (ISO14443A). The following cards are supported:
Type of Card Read Range (EPO200)
ISOProx® II Card 76mm (3.0in)
ProxCard™ Plus Card 38mm (1.5in)
ProxCard® II Card 76mm (3.0in)
ProxKey™ II Fob
25mm (1.0in)
Kantech 31bit Card 38mm (1.5in)
Type of Card Read Range (EPO210)
Mifare Card 30mm (1.18in)
local database
Provides storage of up to 197,000 cardholders at the door and
is retained in excess of three months without external power.
The EtherProx can also store up to 50,000 transactions in offline
operation.
Built-in diagnostics
Allows testing of LED indicators, LCD display, read head, inputs,
relay, network communications, keypad and database size.
Ethernet connectivity
The EtherProx has an integral 10 base-T Ethernet interface
enabling the EtherProx to be connected directly to the LAN at
10Mbits/sec.
PRodUcT highlighTS
CEM/B/136
