4.6 Sensor
The Sensor Window allows you to enable, disable and configure Sensors.
Type – Selects whether the Sensor will be Normally Open (NO) or Normally Closed (NC).
Delay
(sec)
– Adjusts the amount of time (in seconds) to ignore the sensor if it is continuously activated.
Relay
– Selects the Control Output to activate once the Sensor has been tripped.
1
2
3
Figure 4.6
Figure 4.6
Sensor
2
1
3
