l LCD-1900VR 19” LCD 8U Rack Display Monitor
Overall Dimension (HxWxD): 394.5 x 436 x 62 mm
Effective Display area (H/V): 376.32 x 301.56 mm
Display colors: 16.7M colors
Scan Frequencies:
Horizontal 31.47K to 80KHz
Vertical 60Hz to 75Hz
Number of Pixels: 1280x1024 pixels
Pixel pitch: 0.294x0.294 mm
Picture Tube: 19" TFT LCD panel
Power:
Input 110-240VAC (auto-sensing)
Frequency: 48-62Hz
Consumption 45Watts maximum (on)
3 Watts (Power saving off mode)
PC RGB Connector: 15pin Mini D-sub (Standard)
Audio connector 1 x stereo input
Speaker 2W x 2
RGB Signals:
Video Analog RGB 0.7Vp-p/75
Ω
Sync Separate
Display Data Channel:
Compatibility VESA DDC 1/2B
Video connector input
S-connector x 1 (S-Video In)
AV connector x 3 (one for Composite Video
Two for audio left/right)
Mini D type x 1 (for YcbCr/Component In)
BNC connector x 1 (Composite Video In)
Video connector output
BNC connector x 1 (Composite Video Out)
