Peripheral Equipment
183
XGA (1024x768) 60Hz
HD720p (1280x720) 50,60 Hz
DVI and specifications:
DVI stands for Digital Video Interface, and is a form of video interface technology made to
maximize the quality of flat panel LCD monitors and high-end video graphics cards.
The TANDBERG codec contains a DVI-I plug that can transmit either digital DVI signals or
standard analog VGA signals, depending on what type of monitor is connected.
DVI Specifications
TANDBERG DVI-I follows the VESA Monitor Timing Standard v1.08, also knows as Display
Monitor Timing (DMT).
Analog
Horizontal
Frequency
Vertical
frequency
Pixel
Clock
800x600 @
75Hz
46.875kHz
75.00Hz
49.50MHz
1024x768
@ 60Hz
48.363kHz
60.004Hz
65.00MHz
Digital
800x600 @
75Hz
46.875kHz
75.00Hz
49.50MHz
1024x768
@ 60Hz
48.363kHz
60.004Hz
65.00MHz
DVI-I Video resolution supported in F1 and above
Supported DVI cables:
TANDBERG supports DVI-D Single-Link, DVI-A and DVI-I Single-Link format cables.
DVI-D cables transmit digital T.M.D.S. signals, DVI-A cables transmit analog VGA signals and
DVI-I cables can transmit either digital or analog signals.
It is possible to extend existing DVI cables by the use of extension cables. The maximum cable
length however, is 5 meters. Going beyond that may result in quality loss.
DVI-I - Combined Analog and Digital Connector Pin Assignments:
Pin
Signal
Assignment
Pin
Signal
Assignment
Pin
Signal
Assignment
1
T.M.D.S.
Data2-
9
T.M.D.S.
Data1-
17
T.M.D.S. Data0-
2
T.M.D.S.
Data2+
10
T.M.D.S.
Data1+
18
T.M.D.S. Data0+
3
T.M.D.S.
Data2/4 Shield
11
T.M.D.S.
Data1/3 Shield
19
T.M.D.S.
Data0/5 Shield
4
T.M.D.S.
Data4-
12
T.M.D.S.
Data3-
20
T.M.D.S. Data5-
