PhysIcal
Size
142 x 115 x 44mm (5.6 x 4.5 x 1.7”)
Weight 370g (13oz) with connectors
Housing Flame retardant polycarbonate containing
fully encapsulated electronics.
Colour Dark and Light Grey
Power
- Voltage
9 – 14Vdc
- Current
Consumption
200mA (passive), 320mA (peak)
EnVIROnmEntal
IP Rating
IP65
Temperature -20° to 50°C (-4° to 122°F)
Humidity Unlimited, also condensing
LED Indicators Three high intensity LED indicators red,
amber and green
LCD Indicators 32 x 122 dots Monochrome Graphics
supertwist LCD with backlight
Keypad 12 character, standard layout, tactile or
non-tactile response keypad.
FunctIOnalIty
Inputs
Four analog inputs – voltage supplied
Outputs Two relays fitted – Changeover volt free
contacts
- Rating 30Vdc @ 5A
- Duration Programmable
Suppression device (diode, MOV, etc.)
required at load
Memory 2 MB battery backed memory
Compact Flash 32 MB Typical (Optional)
Database
Battery Backup
3.0V rechargeable Lithium-Ion
- Cardholders Storage of up to 219,000 cardholders at
the door.
- Transactions Up to 50,000 transactions in offline
operation.
Configuration Operational parameters are downloaded
from host computer. Some configuration
setting can also be set using the keypad.
Standard Door
Operating Modes
Door Access, Passenger, Turnstile,
Verification, Manned Control Post,
Equipment Enable
cOmmunIcatIOn IntERFacE
To Exit Reader
RS485 multidrop cable runs using copper
wire with maximum length of 1.2km
without repeater
Connection 2 part JST Connector
To Host Controller RS485 multidrop cable runs using copper
wire with maximum length of 1.2km
without repeater
Connection 2 part JST Connector
PROduct cOdEs
RDR/611/101
S610s 125khz HID Prox
RDR/611/105 S610s 13.56MHz MiFare
RDR/611/104 S610s Prox & MiFare (Multi-tech)
RDR/611/106 S610s PicoPass™
RDR/611/109 S610s External Read Head
CEM Systems Ltd Unit 4 Ravenhill Business Park Ravenhill Road Belfast BT6 8AW Northern Ireland
Tel: +44 (0)28 9045 6767 Fax: +44 (0)28 9045 4535 email: [email protected]
www.cemsys.com
PRODUCT HIGHLIGHTS
CEM/B/021
Product specifications and availability is subject to change without notice. Certain product names mentioned herein may be trade names
and/or registered trademarks of their companies.
tEchnIcal sPEcIFIcatIOns
host communications
The S610s has an RS485 serial port allowing it to
communicate directly with the host AC2000 controller.
Onboard card Reading technologies
The S610s supports onboard head technologies for 125 KHz
Proximity, 13.56 MHz MiFare and Inside PicoPass, as well as
a multi technology version supporting Proximity + MiFare.
Other technologies can be supported using the two available
onboard Wiegand connections.
Proximity to miFare smartcard migration
The S610s multitech version supports the simultaneous
reading of both traditional Proximity and MiFare cards.
The enables existing sites using proximity card to migrate
to MiFare smartcards with zero system downtime and no
reduction in security. The MiFare card can be used for other
applications such as cashless vending, Biometric storage,
logical access, etc.
Off-line card Validation
The card database is initially downloaded to the reader’s
memory from the host computer with subsequent changes to
card data automatically sent as updates. This ensures that
the reader has up-to-date card information when operating in
off-line mode. Operating in off-line mode the reader can hold
in excess of 200,000 cards.
Reader messages
The S610s has a large graphical LCD which is used to
display a number of predefined messages to cardholders
depending on their privileges e.g. Wrong Zone, Lost/Stolen
Card, Card About to Expire, Access Granted etc. Messages to
be displayed by the S610s can be modified by the AC2000
software or translated into local languages.
Remote Programming
The S610s reader may be remotely programmed from the
host computer, eliminating the need to physically replace
firmware, giving increased system flexibility and efficiency.
Operational parameters, e.g. door open time, can also be
downloaded to the reader.
