40
Maximum PPS Table
PPS Breakdown for Each Resolution
Resolution CCTV XVR4-120 model
360x240 1CIF 120 PPS
720x240 * 2CIF 120 PPS
720x480 ** 4CIF 60 PPS
* Frames recorded in 720x240 are twice the size of the standard 360x240. When recording at
720x240, each frame assigned to the channel will use 2 of the total frames available.
** Frames recorded in 720x480 are four times the size of the standard 360x240. When recording at
720x480, each frame assigned to the channel will use 4 of the total frames available.
Resolution CCTV XVR16-60 model XVR16-120 model
320x240 1CIF 60 PPS 120 PPS
640x240 2CIF 60 PPS 120 PPS
640x480 4CIF 30 PPS 60 PPS
