Toshiba XVR16-120-X - Manual (Page 114)

100
Create a New Remote Connection
1. Select Start > Programs > Surveillix > Remote > Surveillix Remote Center. The Surveillix Remote Software opens and the Local
Connection window opens.
2. Click New to open the Site Info window.
3. Select the Site Type and enter a Site Name. The Site Name will be the name displayed inside the connection box to help
identify the server.
4. Enter the IP Address of the XVR server. By default the XVR is set to connect using DHCP.
5. Enter the Center Port. This setting is specified on the server.
6. Click OK.
7. Click the newly created connection and enter the login username and password. (case sensitive)
8. Click Connect.
DVR Site List
Selected Site Information
Import/Export saved configurations
