Issue A Rev 2
108469
Telect, Inc.
1-1
D
IGITAL
N
ETWORK
I
NTERFACE
P
ANEL
Telect’s DNI-3 is a multifunction support panel for DS3 telecommunica-
tions networks. It is an accessible and centralized interconnect point be-
tween digital cross-connect systems (DCSs) and central office network ele-
ments (NEs).
The DNI-3 panel serves as a platform for circuit configuration changes,
maintenance activities, and troubleshooting procedures. The DNI-3 be-
comes an extension of the DCS backplane that provides complete circuit
access, thus removing the risk of interrupting DCS operations.
Capabilities
•
High circuit densities (up to 1280 coax cables per panel)
•
Efficient circuit migration for system expansion
•
Quick circuit patching, troubleshooting, and monitoring
•
Compatability with all DS3, STS1, and STS3 signal types and system
management software
Features
•
Mini-WECO Twist Lok™ jacks (TLJs)
•
Circuit designation labels
•
Hinged designation holders
®
®
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
M
O
I
M
O
I
NE-2
NE-1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
M
O
I
M
O
I
NE-2
NE-1
1
Descriptions
