Telect T3 User Manual
Page 16
User Functions
DNI-3 User Manual
4-4
Telect, Inc.
108469
Issue A Rev 2
Step
Action
1.
To monitor the NE circuit outputs, insert a Mini-WECO patch cord
into the NE (upper) Monitor TLJ.
To monitor the DCS circuit outputs, insert a Mini-WECO patch
cord into the DCS (lower) Monitor TLJ.
2.
Connect the other end of the the patch cord to the test set to com-
plete your connection and perform monitoring.
