35 3M ™ Multimedia Projector MP7630 © 3M IPC 2000
Appendix
Technical Specifications
✓ Note: All specifications are subject to change without notice.
General
Product name Multimedia Projector
Model name MP7630
Optical
Display system 1-CHIP DMD
Lens F/Number: F/2.7 – F/3.4 Focal Length: F = 72 – 108 mm (2.8 in. – 4.3 in.)
Lamp 150 W UHP lamp
Electrical
Power supply AC100 ~ 240V, 6.5A ~ 2.9A, 50/60 Hz (Automatic)
Power consumption 200 W (Max)
Mechanical
Dimensions 8 in. (W) x 2.6 in. (H) x 9.7 in. (D)
202 mm (W) x 67 mm (H) x 264 mm (D)
Operating
temperature range 32
°
~ 95
°
F (0
°
~ 35
°
C)
Weight 2.27 kg (5 lbs.)
Input/Output terminal
Video signal
input terminal S VIDEO : Mini DIN 4-pin terminal
VIDEO : RCA Jack terminal + BNC
AUDIO : RCA Jack terminal
RGB input/output
signal terminal RGB signal : D-sub 15-pin (Female)
AUDIO : RCA Jack + BNC
Control terminal D-sub 9-pin (Male)
Mouse MD 9-pin (serial/PS2/ADB)
