PhysIcal
Size

- Board Only 192 x 145 x 20mm

(7.6” x 5.7” x 0.8”)

- Enclosure

460 x 250 x 90mm

(18” x 10” x 3.5”)

Weight - Board Only 0.1Kg

- Enclosure

5.00kg

Housing

Wall mount 1.2mm steel enclosure

Colour

Grey

Power Board Only:

- Voltage

9 – 14Vdc

- Current

Consumption 170mA (excluding locks and heads)

Enclosure:

- Voltage

220-230 VAC 50/60Hz

- Current

Consumption 200mA (excluding locks and heads)

Backup Battery

Integral charging circuit provided with

enclosure and space battery

(Battery not supplied)

Environmental

- Temperature -10º to 55°C (14° to 133°F)

LED Indicators

Power, Link to host, Comms Tx/Rx, Fault /

Tamper, Lock and Relay Status

FunctIOnalIty
Inputs

* Door Position

* Lock Status

* Exit Push Button

* General Purpose

Power Fail

Tamper

Battery Low (reported internally)

Dedicated Power Fail Input

* = 4 state tamper protected inputs

Outputs

Two Relays rated at 30V@5A

Two 12V open collector outputs

limited to 1.5A (Door Lock and

External Sounder)

Reader capacity

2 Weigand/Mag Stripe interfaces

(data/data, clock/data)

Configuration

Operational parameters are downloaded

from host computer

Database memory

1GB SD Card

Cardholders

Storage up to 200,000 cardholders

at the door

Transactions

Up to 50,000 transactions in offline

operation

RTC Battery Backup

3.0V rechargeable Lithium-

Configuration

Operational parameters are downloaded

from host computer

cOmmunIcatIOn IntERFacE
To Readers

Weigand/Mag Stripe interface

(data/data, clock/data)

Connection

2 part screw terminals

To System Host

10/100 Base-T TCP/IP using CAT5

Unshielded twisted pair cable

Connection

RJ45

PROduct cOdEs
DCM/300/004

DCM 300e (Board Only)

DCM/300/101

DCM 300e (Includes enclosure, board &

power supply/battery charger)

CEM Systems Ltd Unit 4 Ravenhill Business Park Ravenhill Road Belfast BT6 8AW Northern Ireland

Tel: +44 (0)28 9045 6767 Fax: +44 (0)28 9045 4535 email: [email protected]

www.cemsys.com

PRODUCT HIgHLIgHTS

CEM/A/051/ Rev B

Product specifications and availability is subject to change without notice. Certain product names mentioned herein may be trade names
and/or registered trademarks of their companies.

tEchnIcal sPEcIFIcatIOns

host communications

The DCM 300 has an on-board 10/100 Mbps Ethernet allowing
it to communicate directly with the AC2000 host central
system.

On-board card Reading technologies

The DCM 300 supports a wide range of head technologies
using the two available on-board Wiegand connections.
Supported card technologies include Wiegand 26bit, CEM
37bit, Mifare, Corporate 1000 and many more.

Off-line card Validation

The card database is initially downloaded to the reader’s

memory from the host computer with subsequent changes to
card data automatically sent as updates. This ensures that
the reader has up-to-date card information when operating in
off-line mode. Operating in off-line mode the reader can hold
up to 200,000 cards.

Easy to Install

The DCM 300 is designed to be extremely easy to install.
The installer simply enters the units preconfigured IP address
on the AC2000 workstation, provides it with power, connects
to an Ethernet network and the reader self-configures
and receives up to 50,000 cardholder database in under 2
minutes.
