Tyan Computer THUNDER N3600T User Manual

Page 13

background image

13

http://www.TYAN.com

Jumper Legend

OPEN - Jumper OFF

Without jumper cover

CLOSED - Jumper ON

With jumper cover

To indicate the location of pin-1

To indicate the location of pin-1

JP1

JP2

JP3

J2

J26

This manual is related to the following products:

THUNDER S2937
