11
Using a screw driver, turn adjustment
screws in rollers left or right until panel
is level and glides smoothly across the
track.
Close panel to within 1/4 of lock jamb.
Use visual margin to assure panel is
adjusted straight with frame. "
ADJUST ROLLERS
17
INSTALL ACTIVE PANELS
16
Head Jamb
Exterior
Interior channels
Interior
From interior side of system, install active
panel up into interior channels in head jamb.
Push upwards as far as possible and rotate
into place until rollers engage sill roller track.
As a reference, the exterior side of the
panel is always the pre-finished side.
Repeat for second active panel.
To inactive panel To center of unit
