Texas Instruments TAS5110D6REF User Manual
Page 40
TI
TAS5110D6REF PCB SPECIFICATION (1.00)
Claus Reckweg
Page 1 of 1
TAS5110D6REF PCB SPECIFICATION
BOARD IDENTIFICATION:
P167-PCB-001 (1.00)
BOARD TYPE: Double-sided plated-through board
LAMINATE TYPE:
FR4
LAMINATE THICKNESS: 1,6 mm
COPPER THICKNESS: 70 µm (including plating exterior layer)
COPPER PLATING OF HOLES: >25 µm
MINIMUM HOLE DIAMETER 0,3 mm
SILKSCREEN COMPONENT SIDE: White-remove silkscreen from solder area and pretinned areas
SILKSCREEN SOLDER SIDE:
None
SOLDER MASK COMPONENT SIDE: Green
SOLDER MASK SOLDER SIDE: Green
PROTECTIVE COATING: Solder coating and chemical silver on free copper
ELECTRICAL TEST: PCB must be electrical tested
MANUFACTURED TO:
PERFAG 2E (www.perfag.dk)
APERTURE TABLE:
PERFAG 10A (www.perfag.dk)
BOARD SIZE:
105 x 127 mm
