Ref Des Part Number Description Housing Manufacturer Manufacturer Part Number
L481 350101031 10uH 8A 10% 28mR TOKIN SBPSC-11R310-100A
LED121 405000810 RED 10mA LED SMD 0603P Toshiba TLSU1008
LED122 405000810 RED 10mA LED SMD 0603P Toshiba TLSU1008
LED123
405000820 GREEN 10mA LED SMD 0603P Toshiba TLGU1008
LED120 405000830 YELLOW 10mA LED SMD 0603P Toshiba TLYU1008
Q120 425229070 PNP 40V/800 mA small signal transistor SOT-23 Fairchild MMBT2907A
Q121 425229070 PNP 40V/800 mA small signal transistor SOT-23 Fairchild MMBT2907A
Q122 425229070 PNP 40V/800 mA small signal transistor SOT-23 Fairchild MMBT2907A
U200 500051101 TDAA PWM Power Output Stage, DAD package HTSSOP32 Texas Instruments TAS5110DAD
U220
500051101 TDAA PWM Power Output Stage, DAD package HTSSOP32 Texas Instruments TAS5110DAD
U300 500051101 TDAA PWM Power Output Stage, DAD package HTSSOP32 Texas Instruments TAS5110DAD
U320 500051101 TDAA PWM Power Output Stage, DAD package HTSSOP32 Texas Instruments TAS5110DAD
U400 500051101 TDAA PWM Power Output Stage, DAD package HTSSOP32 Texas Instruments TAS5110DAD
U420 500051101 TDAA PWM Power Output Stage, DAD package HTSSOP32 Texas Instruments TAS5110DAD
U111 510102721 Dual RtR Output OPAMP MSOP8 Texas Instruments TLV272CDGK
U110 520141261 Dual buffer with output enable, LVC MSOP8 Texas Instruments SN74LVC2G126DCT
U130 520141261 Dual buffer with output enable, LVC MSOP8 Texas Instruments SN74LVC2G126DCT
U140 520141261 Dual buffer with output enable, LVC MSOP8 Texas Instruments SN74LVC2G126DCT
U170 540251330 3.3 V/1.5A low drop Lin. Reg. HTSSOP20 Texas Instruments TPS75333QPWP
MECH1 600100050 P167-MECH-002 (1.00) GTV P167-MECH-002 (1.00)
MECH2 600100060 P167-MECH-003 (1.00) GTV P167-MECH-003 (1.00)
MECH2 600100070 P167-MECH-004 (1.00) GTV P167-MECH-004 (1.00)
SCREW01 600200010 M3x6 Pozidriv stainless steel screw Bossard BN 31108 M3x6
SCREW02 600200010 M3x6 Pozidriv stainless steel screw Bossard BN 31108 M3x6
SCREW03 600200010 M3x6 Pozidriv stainless steel screw Bossard BN 31108 M3x6
SCREW04 600200020 M3x10 Pozidriv stainless steel screw Bossard BN 31108 M3x10
SCREW05 600200020 M3x10 Pozidriv stainless steel screw Bossard BN 31108 M3x10
SCREW06 600200020 M3x10 Pozidriv stainless steel screw Bossard BN 31108 M3x10
WASHER01 600400010 M3 stainless steel washer Bossard BN 670
WASHER02 600400010 M3 stainless steel washer Bossard BN 670
WASHER03 600400010 M3 stainless steel washer Bossard BN 670
WASHER04 600400010 M3 stainless steel washer Bossard BN 670
WASHER05 600400010 M3 stainless steel washer Bossard BN 670
WASHER06 600400010 M3 stainless steel washer Bossard BN 670
J110 700100021 2 pin 2,54 mm pitch header, friction lock MX2SI Molex 22-27-2021
J160 700100051 5 pin 2,54 mm pitch header, friction lock MX5SI Molex 22-27-2051
J240 700300020 2 Pin 3,96 mm pitch header MY2S JST B 2P-VH
J280 700300020 2 Pin 3,96 mm pitch header MY2S JST B 2P-VH
J340 700300020 2 Pin 3,96 mm pitch header MY2S JST B 2P-VH
All rights belongs to Texas Instruments Incorporated Texas Instruments Incorporated
Appendix A Page 6 of 8 TAS5110D6REF Parts List P167-LST-001(4.00) App A
