Ref Des Part Number Description Housing Manufacturer Manufacturer Part Number
J380 700300020 2 pin 3,96 mm pitch header MY2S JST B 2P-VH
J440 700300020 2 pin 3,96 mm pitch header MY2S JST B 2P-VH
J480 700300020 2 pin 3,96 mm pitch header MY2S JST B 2P-VH
J150 700300040 4 pin 3,96 mm pitch header MY4S JST B 4P-VH
J100 700820500 Box header straight 50 pin 2,54 mm IDC50 Multicomp MC9A12-5034
PCB 900116710 P167-PCB-001(1.00) Printline P167-PCB-001(1.00)
C132 Deleted Deleted
C133 Deleted Deleted
C134 Deleted Deleted
C209 Deleted Deleted
C229 Deleted Deleted
C309 Deleted Deleted
C329 Deleted Deleted
C409 Deleted Deleted
C242 Not used Not used
C243 Not used Not used
C244 Not used Not used
C282 Not used Not used
C283 Not used Not used
C284 Not used Not used
C342 Not used Not used
C343 Not used Not used
C344 Not used Not used
C382 Not used Not used
C383 Not used Not used
C384 Not used Not used
C442 Not used Not used
C443 Not used Not used
C444 Not used Not used
C482 Not used Not used
C483 Not used Not used
C484 Not used Not used
J101 Not used Not used
J102 Not used Not used
R261 Not used Not used
R262 Not used Not used
L260 Trace A trace in the PCB
L261 Trace A trace in the PCB
L262 Trace A trace in the PCB
All rights belongs to Texas Instruments Incorporated Texas Instruments Incorporated
Appendix A Page 7 of 8 TAS5110D6REF Parts List P167-LST-001(4.00) App A
